Visinova 4G Front & Rear Dual Dsahcam（ADG-011）

Category

Type

Parameter

System

Operating System

Linux

Concurrent Online Users

Support 4 users to view online simultaneously

APP

Domestic: Xiaoying Guard; Overseas: HotKam

Acquisition

Processor

CV610 Cortex-A7, 1T computing power

RAM

1Gbit

Image Sensor

4MP 1/3 16:9 CMOS Sensor

Viewing Angle

Diagonal D 125°

Crash Sensor

G-Sensor 3-axis accelerometer, collision & gravity sensing

Video

Compression Standard

H.264 / MJPEG / JPEG

Front Camera

Main stream: 2560×1440P@30fps; Sub preview stream: 1280×720P@25fps2G4P D125° 17-lens

Rear Camera

Main stream: 1920×1080P@25fps; Sub preview stream: 1280×720P@25fpsAHD / 2.5mm AV earphone, 5.5m extension cable for rear camera

Screen

1.47-inch SPI screen for live preview & status display

Audio

Input

Built-in -38dB Microphone

Sampling Frequency / Bit Width

16KHz / 16bit

Compression Standard / Bitrate

G.711A

Alarm Recording

Crash Alarm

Push alarm event to cloud when vehicle collides or vibrates, notification on mobile APP

Human Detection

Human detection algorithm, parking sentinel mode

Network

4G Network

North America FDD: B2/B4/B5/B12/B13/B25/B26Asia, Europe & Africa FDD: B1/B3/B7/B8/B20/B28External Nano SIM card slot: 12.3mm × 8.8mm × 0.7mm

Positioning

GPS

Beidou & GPS dual-mode; One-click vehicle search, Geo-fence, track playbackDomestic: Amap; Overseas: Google Maps

Buttons

Reset Button

Long press to restore factory settings

Power Button

Long press power off / short press to lock interesting video (10s)

Storage

Local Storage

Support TF Card (Max. 256GB)

Cloud Storage

1-day free cyclic cloud storage

Working Mode

Driving Mode

Auto detect driving mode, high frame rate 30fps, adjustable driving sensitivity

Parking Monitor

Vehicle ignition-off parking monitoring; multiple monitor modes: sleep collision recording, intelligent all-time recording, time-lapse recording

Alarm Detection

Collision Alarm

Physical Specs

Power Supply

DC12V±5%, Type-C interface

Operating Environment

Operating temperature: -25~70℃; Operating humidity: <90%
